ເມັດສີ 23-Corimax Violet RLS

Pigment violet 23 is an organic compound that is a commercial pigment. It is member of the dioxazine family of heterocyclic compounds, but derived from carbazoles. It is prepared by condensation of chloranil and 3-amino-N-ethylcarbazole. It has a centrosymmetric angular structure. For many years, the structure was assigned, incorrectly, as having a "linear structure" (EC no. 228-767-9, CAS RN 6358-30-1) which differ in terms of the carbazole ring fusion.

Pigment violet 23 is prepared by condensation of an aniline with chloranil.[From Wiki]

ຕົວ ກຳ ນົດວິຊາການຂອງເມັດສີ 23

ດັດຊະນີສີ No.ເມັດສີ 23
ຊື່​ຜະ​ລິດ​ຕະ​ພັນCorimax Violet RLS
ໝວດ ສິນຄ້າເມັດສີອິນຊີ
ຄວາມໄວແສງສະຫວ່າງ (ການເຄືອບ)7
ຄວາມຕ້ານທານຄວາມຮ້ອນ (ການເຄືອບ)200
ຄວາມໄວແສງສະຫວ່າງ (ພາດສະຕິກ)7
ຄວາມຕ້ານທານຕໍ່ຄວາມຮ້ອນ (ພາດສະຕິກ)250
ສີ
ເມັດສີ-violet-23-ສີ
ການແຈກຢາຍ Huepv

Zeyachem is a global supplier of Dioxazine Violet pigments that provide a bluish violet shade, a color not obtainable by other pigments.

The extremely high color strength of Pigment violet 23 makes it a suitable pigment as a shading component. PV23 also exhibits excellent heat fastness and light fastness properties, making it suitable for inks and many paints and coatings applications.

Corimax Violet RLS is a reddish blue shade Dioxazine Violet (PV23) pigment with very high color strength and excellent overall fastness properties, suitable for inks, paints and coatings, including industrial coatings, powder coatings and automotive coatings.

ຄຸນ​ລັກ​ສະ​ນະ:

low viscosity, high gloss, high color strength. Pigment Violet 23 is a transparent purple violet pigment with high saturation and tinting strength.

C.I.Pigment Violet 23 show good tinting strength in flexible PVC while poor resistance to immigration.

P.V.23 heat resistance above 230℃ in polyolefins, when used in transparent PS, temperature shall below 220℃, above this PV 23 shall decompose. When worked in polyester, it is 280℃ stable in 5 hours, while concentration shall above 0.05%.

The pigment is easy to use and requires no rinsing. To ensure maximum color intensity and proper adhesion to the pulp, a retention agent must be added to the pulp before the pigment is applied. Our pigments are supplied by volume sizes. The actual weight varies, depending upon the density of the pigment.

ໃບ ຄຳ ຮ້ອງ:

ແນະ ນຳ ໃຫ້ໃຊ້ ສຳ ລັບການທາສີລົດຍົນ, ເຄືອບສະຖາປັດຕະຍະ ກຳ, ເຄືອບເຄືອບ, ທາສີອຸດສາຫະ ກຳ, ເຄືອບຜົງ, ເຄືອບຜົງ, ພີພີພີພີ, ຢາງ, PS, PP, PE, PU, ຊົດເຊີຍການໃສ່ຫມຶກ, ນ້ ຳ ທີ່ໃສ່ນ້ ຳ, ຍ້ອມສີລະລາຍ, ຫມຶກ UV.

Pigment Violet 23 (PV 23) has now been around for more than 55 years. Its beginnings go back to 1928, when a patent was filed for the pigment after researchers at the Hoechst company in Germany first undertook the multistage synthesis based on carbazole, an ingredient of coaltar, and chloranile. Until the end of World War II the pigment was only used to process diamine light blue, a direct dyestuff for cotton.

With the invention of reactive dyes, which considerably simplified the dyeing and printing process for cellulose fibers, this application lost its importance. A new and promising use for PV 23 was quickly found due to the pigment’s ability to produce unique colors.

PV 23 has been used as a pigment since 1953. PV 23 belongs to the group of high-performance polycyclic pigments (HPP’s) that are used whenever the requirements for a colorant are particularly high. These include high light fastness and weather fastness, fastness to solvents, and heat stability. In addition, PV 23 stands out by its high coloring power. Under the electron microscope, the crude violet shows a highly granular crystalline form, whereas the pigment particles are miniscule.
—————————————————————————————————————————————————— ———————————————

ຂໍ້ມູນທີ່ກ່ຽວຂ້ອງ

ຄຸນລັກສະນະທາງກາຍະພາບແລະເຄມີ:
Hue ຫຼືເບົາ: ສີມ່ວງສີຟ້າ
ຄວາມຫນາແຫນ້ນຂອງພີ່ນ້ອງ: 1.40-1.60
ຄວາມຫນາແຫນ້ນຂອງຫຼາຍ / (lb / gal): 11.7-13.3
ຈຸດລະເບີດ / ℃: 430-455
ຂະ ໜາດ ອະນຸພາກສະເລ່ຍ / μm: 0.04-0.07
ຮູບຊົງສ່ວນ: cubic / rod
ພື້ນທີ່ ໜ້າ ດິນສະເພາະ / (m2 / g): 45-102
ມູນຄ່າ pH / (slurry 10%): 6.2

ການ ນຳ ໃຊ້ຜະລິດຕະພັນ:ເມັດສີ 23 ແມ່ນ ນຳ ໃຊ້ສ່ວນໃຫຍ່ ສຳ ລັບການໃສ່ສີ, ເຄືອບ, ຢາງແລະພລາສຕິກ, ແລະ ສຳ ລັບການໃສ່ສີຂອງເສັ້ນໃຍສັງເຄາະ
ມັນມີ 124 ປະເພດຂອງບັນດາຮູບແບບການຄ້າຂອງເຄື່ອງ ໝາຍ ສີ. Carbazoazine ແມ່ນຊະນິດຂອງສີມ່ວງສີຟ້າທີ່ມີການ ນຳ ໃຊ້ທີ່ເຂັ້ມແຂງແລະຜິດປົກກະຕິ, ແລະພື້ນທີ່ສະເພາະຂອງ monolite violet RN ແມ່ນ 74m2 / g. ມັນໄດ້ຖືກນໍາໃຊ້ຢ່າງກວ້າງຂວາງໃນຂົງເຂດຕ່າງໆເຊັ່ນ: ການເຄືອບ, ການພິມຫມຶກ, ການພິມພາດສະຕິກແລະຜ້າແລະການຍ້ອມສີ. ມັນມີຄວາມໄວທີ່ດີທີ່ຈະ varnish ໃນເວລາທີ່ສີ. ມັນສາມາດຖືກນໍາໃຊ້ສໍາລັບການສີແຫ້ງໃນອາກາດ, ສີລົດໃຫຍ່ OEM ແລະສີອົບ, ໂດຍສະເພາະແມ່ນສໍາລັບສີທີ່ເຮັດດ້ວຍນ້ໍາຢາງທີ່ມີໂຕນ toner CuPc ແລະສຽງເບົາ. ມັນສາມາດຖືກນໍາໃຊ້ສໍາລັບການໃສ່ສີພາດສະຕິກ, ດ້ວຍຄວາມຕ້ານທານຄວາມຮ້ອນ 280 ℃ໃນ polyolefin ແລະການຮັກສາສີສູງ (ພຽງແຕ່ 0.07% ຂອງຄວາມເຂັ້ມຂອງເມັດສີແມ່ນຈໍາເປັນສໍາລັບ HDPE ກັບ 1 / 3SD); ມັນຍັງສາມາດຖືກນໍາໃຊ້ສໍາລັບການໃສ່ສີຂອງ polyester ແລະ PE.

ຫຼັກການສັງເຄາະ: Carbazole ຖືກນໍາໃຊ້ເປັນວັດຖຸດິບ, ແລະ N-ethylation ຖືກປະຕິບັດພາຍໃຕ້ຄວາມກົດດັນປົກກະຕິໃນເວລາທີ່ມີຕົວກະຕຸ້ນໃນໄລຍະ, ແລະປະຕິກິລິຍາຂອງ nitration ແລະປະຕິກິລິຍາຫຼຸດຜ່ອນແມ່ນປະຕິບັດເພື່ອສັງເຄາະ 2-amino-N-ethylcarbazole; ທາດ 3,5,6-tetrachloroparaquinone (Chloranil) ແມ່ນມີອາການປົນເປື້ອນແລະປະຕິກິລິຍາປິດວົງແຫວນ, ກັ່ນຕອງ, ລ້າງດ້ວຍນ້ ຳ, ແລະຕາກໃຫ້ແຫ້ງເພື່ອໃຫ້ໄດ້ສີມ່ວງ carbazole; ສຸດທ້າຍ, ການຮັກສາເມັດສີທົ່ວໄປໂດຍການຄຸເຂົ່າຫຼືຄຸເຂົ່າເພື່ອໃຫ້ໄດ້ຮັບເມັດສີ CI 23.

ນາມແຝງ:Pigment Violet RL; 51319; C.I. Pigment Violet 23; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)tri- phenodioxazine; CI 51319; Diindolo(3,2-b:3',2'-m-)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; Carbazole Dioxazine Violet; Carbazole Violet; Chromofine Violet RE; Cyanadur Violet; Dioxazine Violet; Dioxazine purple; EB Violet 4B7906; EMC Violet RL 10; Fastogen Super Violet RN; Fastogen Super Violet RN-S; Fastogen Super Violet RTS; Fastogen Super Violet RVS; Helio Fast Violet BN; Heliofast Red Violet EE; Heliogen Violet; Heliogen Violet R Toner; Hostaperm Violet RL; Hostaperm Violet RL Special; Hostaperm Violet RL Special 14-4007; Lake Fast Violet RL; Lake Fast Violet RLB; Lionogen Violet R 6100; Lionogen Violet RL; Lionol Violet HR; Monolite Fast Violet R; PV Fast Violet BL; PV Fast Violet RL-SPE; Paliogen Violet 5890; Paliogen Violet L 5890; Permanent Violet; Permanent Violet R; Sandorin Violet BL; Sanyo Permanent Violet BL-D 422; Sumikacoat Fast Violet RSB; Sumitone Fast Violet RL; Sumitone Fast Violet RL 4R; Sumitone Fast Violet RLS; Symuler Fast Violet BBL; Symuler Fast Violet BBLN; Unisperse Violet B-E; Vynamon Violet 2B; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)triphenodioxazine; Diindolo(3,2-b:3',2'-m)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; 8,18-dichloro-5,15-diethyl-5,15-dihydrocarbazolo[3',2':5,6][1,4]oxazino[2,3-b]indolo[2,3-i] phenoxazine

ໂຄງສ້າງໂມເລກຸນ:ເມັດສີ-violet-23-ໂມເລກຸນ - ໂຄງສ້າງ
